Mustang Ii Rack And Pinion High Pressure Port

Your order may be eligible for ship to home and shipping is free on all online orders of 35 00.

Mustang ii rack and pinion high pressure port.

High pressure from the pump into the rack the return fitting is 6an. Refer to protech 22 0010 for more information. Order rack pinion complete unit for your 1978 ford mustang ii and pick it up in store make your purchase find a store near you and get directions. The pressure port in the rack is the 1 2 20 port.

3 4 36 spline input shaft. Rack has 9 16 18 female o ring high pressure inlet and 5 8 18 female o ring low pressure outlet return line threaded ports. Work out your hose routing and decide where to use each hose end extra hose ends and hose are available. The high pressure fitting is the m14x1 5 thread port which is toward the front of the rack and the return fitting is m16x1 5 thread port that is at the rear closest to the pinion input shaft.

Chevy which has a chevy pump with a mustang power rack pinion. The pressure port is m14 1 5 o ring. Transfer the check valve to the replacement unit. This set adapts an aftermarket 1982 1988 t bird cougar type rack or our 91034340 pow rack to a gm style pump.

The kit comes with 90ohose ends. An adapters on both rack ports and the pump pressure port. Check here for special coupons and promotions. Help identify this rackpostssep 2010rack and pinion line connections.

This power rack has a v style input shaft and uses the same tie rod ends as the mustang ii rack. The return port is m16 1 5 o ring. Uses 910 4047 6an adapter fittings. Replacement sku for rack and pinion hard lines is 910 35344.

The original rack pinion may have a removable check valve in the pressure port. Use the figures above to determine the correct port for the check valve. Stan the small port is high pressure big port is low pressure. Begin the installation by assembling the proper adapters into the pump and rack pinion.

Must use offset bushings 910 34342 to mount to original mustang ii crossmembers.
